Vibrating Screen

High-efficiency aggregate grading and sorting for commercial quarries.

High amplitude circular vibration
Adjustable eccentric weights
Multi-deck configurations
Polyurethane or woven wire mesh options
Heavy-duty shock absorbing springs

Get a Quote

Download specification PDF

Capacity60–250 TPH
Price, ex-works Hyderabad₹7,00,000 + GST
Warranty6–12 months, by product
Dispatch6–30 days from order
QualityISO 9001:2015 Certified

Overview

SREW Projects Circular Vibrating Screens are designed for continuous, heavy-duty operation in aggregate and mining applications. Engineered with advanced exciter technology, these screens provide consistent stratification and precise material separation across multiple decks.

High Efficiency

Maximum screening output

Multi-Deck

Up to 4 classification decks

Durable Build

Huck-bolted side plates

Low Maintenance

Easy mesh replacement

How It Works

Material is fed continuously onto the top deck. The circular vibratory motion, generated by eccentric shafts, causes the material to travel down the inclined screen surface. Smaller particles pass through the mesh apertures while oversized material cascades to the discharge end.

At a glance

Capacity: 60–250 TPH
Price: ₹7,00,000 + GST
Warranty: 6–12 months, by product
Dispatch: 6–30 days from order confirmation

See the full specification table

Get a Quote WhatsApp

*Note: Capacity may vary depending on feed material, size, and moisture content.

Complete Specifications Matrix

Model	Deck Size	Decks	Capacity (TPH)	Motor
SREW-VS164	16 ft x 4 ft	3	60 – 80	15 kW / 20 HP
SREW-VS-HD	Larger decks (to order)	2 – 3	100 – 250	15–55 kW / 20–75 HP
High frequency 3-deck screen (₹7,00,000 + GST)	8 ft x 4 ft	3	100 – 200	On request

Price: High frequency vibrating screen, 3 deck (8 ft x 4 ft, linear, 100–200 TPH): ₹7,00,000 + GST (₹8,26,000 incl. 18% GST) (ex-works Hyderabad).
