VSI Crusher (Vertical Shaft Impactor)

High performance sand making machine for superior shape & consistent quality.

Excellent cubical shape
High reduction ratio
Low operating cost
Easy maintenance
Suitable for hard & abrasive materials

Get a Quote

Download specification PDF

VSI crusher by SREW Projects on a white background

Capacity30–250 TPH
Price, ex-works HyderabadFrom ₹12,00,000 + GST
Warranty6–12 months, by product
Dispatch6–30 days from order
QualityISO 9001:2015 Certified

Overview

SREW Projects VSI Crusher is designed for high performance and consistent quality of manufactured sand. It is widely used in the final stage of crushing process to produce high quality cubical shaped sand which meets construction industry standards.

High Efficiency

More Output

Consistent Quality

Superior Cubicity

Durable & Reliable

Longer wear life

Low Maintenance

Easy access roof

How It Works

Material is fed into the center of the rotor through the feed tube. The high speed rotor accelerates the material and throws it against the anvil ring. The material is then crushed by impact and attrition between rock on rock inside the crushing chamber.

At a glance

Capacity: 30–250 TPH
Price: From ₹12,00,000 + GST
Warranty: 6–12 months, by product
Dispatch: 6–30 days from order confirmation

See the full specification table

Get a Quote WhatsApp

*Note: Capacity may vary depending on feed material, size, and moisture content.

Complete Specifications Matrix

Model	Max Feed (mm)	Capacity (TPH)	Motor	Crusher Weight
SREW-V500	30	30 – 40	55 kW / 75 HP	~4.2 t
SREW-V1000	30	65 – 90	75 kW / 100 HP	~4.6 t
SREW-V1200	43	80 – 140	90 kW / 125 HP	~6.4 t
SREW-V2500	45	180 – 250	187 kW / 250 HP	~9.7 t
